More FreeCAD exercises.

 Uncategorized  Comments Off on More FreeCAD exercises.
Oct 122019


I’m trying to get the steps needed to get this fuselage shape drawn documented. This will be the part that the undercarriage has to connect to.

Insert the image
Scale it to the correct dimensions
Shift it to the 0,0 origin (just for easiness)
Draw a B-Spline curve
Do another and shift it backwards 190mm
Select curved shapes, identify the 2 lines, and voila!

The back curve should have a sharper corner, I’ll work on that. Next step is adding the leg and try the fillet parts…

And we have a leg. Next the hardest part yet, a smooth transition between leg and fuselage.
